HVB 32
Universal broadband amplifier
- Broadband amplifier with active 65 MHz return path
- high modulation of the return path for operational reliability even with multi-channel load
- Pre-gain 32 dB
- Output level Pre-way 101 dBµV
- Return path gain 26 dB
- Output level return path 112 dBµV (6 carriers in RW each 8 MHz / QAM256)
- Attenuation Pre-travel 0 - 15 dB in input, attenuator
- Equalizer pre-path 0 - 15 dB in input, attenuator
- Interstage Slope 0 or 7 dB, pluggable
- Attenuation in return path 0 - 15 dB in input, attenuator
- Interstage slope in the return path 3 dB fixed
- Vodafone GmbH certified, type class B(3.2)
EAN-Code: 4026187195885 | Order number: 00217353
| Amplifier series | HV series |
|---|---|
| Local or remote powered | Local powered |
| Frequency range | up to 1006 MHz |
| Gain | 30 - 34 dB |
| Output level (linear) | 98 - 105 dBµV |
| Approval network operator | Vodafone GmbH |
Related keywords: 217353, broadband amplifier, Vodafone certified, type class B(3.2), HVB 32, HVB32
