OFN200-FR-1310 AC
Modular optical CATV Node
- FTTB/FTTC optical Node
- Downstream reception of CATV signals
- integrated 3 dBm / 1310 nm upstream transmitter
- optical input power -7 ... +2 dBm
- nominal output level >108 dBµV (@ OMI 3,5%)
- electronically adjustable attenuation and equalizer
- RF frequency range 5-65 MHz / 87-1006 MHz
- operational voltage 150 - 265 VAC
- optical connectors SC/APC
EAN-Code: 4026187192990 | Order number: 00212122
| Type of Node | Modular Node |
|---|---|
| Return path | With return path |
| Power supplie(s) | One PSU |
Data sheet OFN200 series DE
Block diagram OFN200-FR
Data sheet OFN200 series EN
Manual OFN200 DE
Manual OFN200 EN
Operating instructions for our professional system technology can be found in the ASTRO Expert section. Please register or log in.
